Product Detail

2PC Floating Ball Valve

High precision
ball& High tightness seat
Long life
ball&seat
The most economical
material combination
The best fire safe
and static resistance safety
Widely applicable
Various driving types

Applied Size: 2"~ 24"

Applied Pressure: CL150~CL600

Applied End Connection: RF, RTJ, BW, Nipple End. etc.


PRODUCT FEATURE

High precision ball& High tightness seat

Long life ball&seat

The most economical material combination

The best fireproof, anti-static and anti-resistance

Applicable widely

Various operation types

Split body side entry design.
Full bore or reduced bore.
Ball coating: ENP, TCC, STL, CCC

Locking device (or safety interlock key).
Fire safe design, anti-static device.
Blowout proof stem design.
Body vent device.
Stem extension for underground & cryogenic service.


PRODUCT PARAMETER

Main Material: WCB, WCC, LCB, CF8, CF8M, CF3, CF3M, CN7M, CF8C, 4A, A105, LF2, F304, F316, F304L, F316L, F321, F51, etc.

Applied Standard: API. ASME, ANSI, DIN, etc.

Applied Temp.: -29°C~350℃

Optional operation: Manual, Gear, Electric, Pneumatic, Hydraulic.


ACTUATOR MOUNTING ( ISO-5211)

Flanged end products shall have an integrally cast actuator mounting pad. This feature provides for direct mount of gear operators or actuators. The additional cost for a separate mounting bracket is eliminated.


LIVE LOAD STEM SEAL

The combination of stem packing and O-rings guarantee zero emissions even at low pressure. The primary seal is made out of flexible graphite , a material with extremely good resistance to fire conditions. The anti blow out stem is inserted from inside the valve body
